Description
Double Channel Base Plate (6-Hole 2+4)
The Double Channel Base Plate (6-Hole) is a premium anchor fitting for back-to-back (double) strut channel. This plate uses six total fixing points to deliver the highest stability. It is the best choice for securing heavy vertical columns, equipment skids, and large framing systems.
This base plate is built for performance, ensuring your heaviest structures are safely and permanently secured.
- Maximum Anchoring: The dedicated 4 hole structural anchor pattern provides exceptional pull-out and shear resistance, surpassing the stability of standard plates.
- Superior Load Spread: The large surface area and six fixing points work together to safely distribute the heaviest compressive loads from your channel structure onto the foundation.
- Precision Fit: Two central holes secure the double channel base firmly, eliminating movement and maintaining the structural integrity of your vertical or horizontal run.
- Finish: Hot Dip Galvanised (HDG) to BS EN ISO 1461, providing maximum corrosion protection against moisture and environmental factors.
Zinc plated and stainless steel are also available on request.
We also supply cantilever arms, channel nuts and setscrews.
 |
 |
 |
